SU0121S03 — CCEA Lights LED machine light
SUBRA, 160 mm, 6 W, 24 Vdc, IP67, 120°, 5000K 3STEP MacAdam, M12A-4P Male connector
Power6 W24 Vdc
Flux485 lm80.83 lm/W
Optics120°IP67
Light colour5000 K3STEP MacAdam · CRI 80
Operational data
- IP protection
- IP67
- IK resistance
- IK06
- Operating temperature
- -20°C / +45°C
- Wiring
- Connector · M12A-4P Male
- Light source
- LED
Construction
- Front protection
- TEMPERED GLASS
- Length
- 160 mm
- Weight
- 0.25 kg
- Finish
- Anodized Silver
Downloads
Accessories
FIXINGS
SUFX01
Stainless steel side bracket kit - Angle adjustment 60°
Photometry
Flux485 lm
Power6 W
Half-peak divergence—
Colour temperature5000 K
Isolines · Plane 1 × 1 m
Plane
Isoline step
Processing photometric file…
Calculation on a horizontal 1 × 1 m plane 1 m from the luminaire, without inter-reflections. Hover a curve to read its lux value.
3D model
Loading 3D…
Certifications
RoHS
Compliance with the EU directive on the restriction of hazardous substances in electronic products
CE
Mandatory marking of compliance with European directives
