FIXINGS
CLAMP04
Metal clamp for 60x60mm base
LYSAR-INDUSTRIAL
LY0321BF1 — CCEA Lights LED machine light
LYSAR-INDUSTRIAL, 6 W, 24 Vdc, IP54, 40°, 5000K 3STEP MacAdam, PUR cable 2x 0.34 mm² (22 AWG) with M12-A 3P Male 2.8 m
Power6 W24 Vdc
Flux455 lm75.83 lm/W
Optics40°IP54
Light colour5000 K3STEP MacAdam · CRI 80
Operational data
- IP protection
- IP54
- IK resistance
- IK06
- Wiring
- Cable · PUR 2x 0,34 mm² (22 AWG) with M12-A 3P Male · 2.8 m
Construction
- Weight
- 1.142 kg
- Finish
- Black Anodized
Downloads
Accessories
FIXINGS
B02
Magnetic base with screw for 60x60mm base
Certifications
RoHS
Compliance with the EU directive on the restriction of hazardous substances in electronic products
CE
Mandatory marking of compliance with European directives
